100 Watt Isolated Dual Output

5 Volts @ 10 Amps & 15 Volts @ 3.4 Amps

Features:

  • ZVT technology to reduce power dissipation and improve efficiency
  • Built in active PFC, PF>0.95
  • Universal AC input/ full range
  • Remote Control on every individual output module
  • Protections: Short circuit / Overload / Over voltage for all output modules
  • Additional 12V/0.1A auxiliary output for remote control
  • Cooling by built-in DC fan with fan alarm function
  • 3 years warranty

Product Identification

Type:Auto Switching SMPS
Product Type:AC to DC Power Supply
Manufacturer Series:MD-100

Compliance

Agency Approvals: TUV, UL, EN

Dimensions & Appearance

Style:Multiple Output
Color:Silver
Length:10 in.
Height:2.5 in.
Width:5 in.

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC

Output

Number of Outputs:2
Output Voltage:5 VDC
Additional Output Voltages (VDC):15
Output Connector Type:Screw Terminal Block
Output Current:10 A

Features

Power Rating:101 W
,
