Rectangular Cermet Potentiometer 22-Turn 1 Watt 20k Ω 10%

Specifications

  • Number of turns: 22
  • Resistance: 20k Ω ±10%
  • Power: 1 watt
  • Adjustment: Side adjust
  • Mounting: 3-pin PC mount
  • Size: 1.25"

    • Product Identification

    Product Type:Trimmer
    Manufacturer Series:3059
    Family:Y

    Dimensions & Appearance

    Width:4.95 mm
    Height:8.13 mm
    Length:31.75 mm
    Shaft Diameter:2.79 mm
    Mounting:Through Hole

    Operating conditions

    Maximum Operating Temperature:150°C
    Minimum Operating Temperature:-65°C

    Features

    Resistance (Ohm):20000
    Taper:Linear
    Resistive Element Material:Cermet
    Actuator Orientation:Side
    Number of Turns:22
    Tolerance:10%
    Temperature Coefficient:100 ppm/°C
    Technology:Sealed
    Power Rating:1 W
    Termination Style:Pins
    Resistance:20 KOhm
    Actuator Type:Side Slot
    ,
