0.47F (470mF) Supercapacitor (EDLC) 5.5 V Axial Can Vertical 50 Ohm

Features

  • Capacitance: 0.47 F (470 mF)
  • Tolerance: -20%, +80%
  • Voltage - Rated: 5.5 V
  • ESR (Equivalent Series Resistance): 50 Ohm @ 1 kHz
  • Lifetime @ Temp.: 1000 Hours @ 70°C
  • Termination: PC Pins
  • Mounting Type: Through Hole
  • Package: Axial, Can - Vertical
  • Lead Spacing: 0.197" (5 mm)
  • Size: 0.453" Dia (11.5 mm)
  • Height - Seated (Max): 0.453" Dia (11.5 mm)
  • Operating Temperature: -25°C to 70°C

Dimensions & Appearance

Diameter:11.50 mm
Height:5 mm
Mounting Feature:Through Hole
Body Orientation:Vertical

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C

Features

Equivalent Series Resistance:50 Ω
Tolerance:-20%, +80%
Voltage Rating:5.5 VDC
Capacitance:0.47 F
Pitch:5 mm
,
