0.01µF Ceramic Capacitor -20%/+80% 50V Z5U Axial

Specifications

  • Capacitance: 0.01µF
  • Tolerance: -20%/+80%
  • Voltage - Rated: 50 VDC
  • Temperature Coefficient: Z5U
  • Operating Temperature: 10°C to 85°C
  • Applications: General Purpose
  • Mounting Type: Through Hole
  • Package: Axial
  • Size: 0.100" Dia x 0.170" L (2.54 mm x 4.32 mm)
  • Lead Style: Straight

Dimensions & Appearance

Diameter:0.1 in., 2.54 mm
Length:0.17 in., 4.32 mm
Dimensions:2.54mm x 4.32mm
Mounting:Through Hole

Operating conditions

Minimum Operating Temperature:10°C
Maximum Operating Temperature:85°C

Features

Construction:Axial
Lead Diameter:0.445 mm
Case Style:Dipped
Dielectric:Z5U
Tolerance:-20%, +80%
Capacitance:0.01 uF, 10000 pF
Voltage Rating:50 VDC
,
